Specifications: ASTM B574 / ASME SB574
Standard: ASTM, ASME and API
Range: 5 mm to 500 mm Dia
Length: 100 mm to 6000 mm
Finishing: Bright, Polish & Black
Form: Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc.
Grade: Hastelloy C276, UNS (N10276), DIN (2.4819)
Mechanical Strength of Hastelloy UNS N10276 Round Bar
|
Element |
Density |
Melting Point |
Tensile Strength |
Yield Strength (0.2%Offset) |
Elongation |
|
Hastelloy C276 |
8.89 g/cm3 |
1370 °C (2500 °F) |
Psi – 1,15,000 , MPa – 790 |
Psi – 52,000 , MPa – 355 |
40 % |
Chemical Compatibility of 2.4819 Hastelloy C276 Rod
|
Grade |
C |
Mn |
Si |
S |
Co |
Ni |
Cr |
Fe |
Mo |
P |
|
C276 |
0.010 max |
1.00 max |
0.08 max |
0.03 max |
2.50 max |
50.99 min* |
14.50 – 16.50 |
4.00 – 7.00 |
15.00 – 17.00 |
0.04 max |
Equivalent grades of Hastelloy C276 N10276 Bright Bar
|
STANDARD |
WERKSTOFF NR. |
UNS |
JIS |
GOST |
EN |
OR |
|
Hastelloy C276 |
2.4819 |
N10276 |
NW 0276 |
ХН65МВУ |
NiMo16Cr15W |
ЭП760 |
Tolerance of Hastelloy UNS N10276 Bright Round Bar
|
Hastelloy C276 round bar Tolerance ISO “H” Series in MM |
||||||||
|
NOMINAL SIZE |
h5 |
h6 |
h7 |
h8 |
h9 |
H10 |
H11 |
h12 |
|
DIAMETER mm |
||||||||
|
~ to 3 |
+0.004/0 |
+0.006/0 |
+0.01/0 |
+0.014/0 |
+0.025/0 |
+0.04/0 |
+0.06/0 |
+0.1/0 |
|
over 3 to 6 |
+0.005/0 |
+0.008/0 |
+0.012/0 |
+0.018/0 |
+0.03/0 |
+0.048/0 |
+0.075/0 |
+0.12/0 |
|
over 6 to 10 |
+0.006/0 |
+0.009/0 |
+0.015/0 |
+0.022/0 |
+0.036/0 |
+0.058/0 |
+0.09/0 |
+0.15/0 |
|
over 10 to 18 |
+0.008/0 |
+0.011/0 |
+0.018/0 |
+0.027/0 |
+0.043/0 |
+0.07/0 |
+0.11/0 |
+0.18/0 |
|
over 18 to 30 |
+0.009/0 |
+0.013/0 |
+0.021/0 |
+0.033/0 |
+0.052/0 |
+0.084/0 |
+0.13/0 |
+0.21/0 |
|
over 30 to 50 |
+0.011/0 |
+0.016/0 |
+0.025/0 |
+0.039/0 |
+0.062/0 |
+0.1/0 |
+0.16/0 |
+0.25/0 |
|
over 50 to 80 |
+0.013/0 |
+0.019/0 |
+0.03/0 |
+0.046/0 |
+0.074/0 |
+0.12/0 |
+0.19/0 |
+0.3/0 |
|
over 80 to 120 |
+0.015/0 |
+0.022/0 |
+0.035/0 |
+0.054/0 |
+0.087/0 |
+0.14/0 |
+0.22/0 |
+0.35/0 |
|
over 120 to 180 |
+0.018/0 |
+0.025/0 |
+0.04/0 |
+0.063/0 |
+0.1/0 |
+0.16/0 |
+0.25/0 |
+0.4/0 |
|
over 180 to 250 |
+0.02/0 |
+0.029/0 |
+0.046/0 |
+0.072/0 |
+0.115/0 |
+0.185/0 |
+0.29/0 |
+0.46/0 |
Physical Properties of UNS N10276 Round Bar
|
Properties |
Metric |
Imperial |
|
Density |
8.89 g/cm³ |
0.321 lb/in³ |
|
Melting point |
1371°C |
2500°F |
